ArmorView Plus 7 Graphic Terminal
SKU: 2711P-T12W22D9P-BM015
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2711P-T12W22D9P-BM015 ArmorView Plus 7 Graphic Terminal is a rugged, brand-free HMI developed for industrial environments that demand high dependability, safety, and customisation.
This arrangement is appropriate for machine-level control applications that require a wide range of operator inputs, robust visualization, and enhanced safety measures.
Buy currently uses Select Automation shop pricing and checkout.
Display & Interface:
Screen Size: 12.1-inch widescreen color touch display.
Resolution: 1280 x 800 (WXGA).
Touchscreen Type: Capacitive.
Operating System: Windows 10 IoT Core.
Performance & Power:
Model Type: Performance model for on-machine use.
Power Input: 24V DC (range: 18–30V DC).
Branding: Brandless configuration for OEM flexibility.
Connectivity & I/O:
Ethernet: Embedded switch supporting DLR, linear, and star topologies.
I/O Configuration: Ethernet I/O with 7 button positions populated.
USB Ports: Available for peripherals and data access.
Button Plate Configuration:
Position 0: 3-position selector switch.
Positions 1–5: Momentary push buttons.
Position 6: ESTOP with legend button.
Software & Functionality:
FactoryTalk® View ME: For application development and runtime visualization.
Remote Access: VNC and FactoryTalk ViewPoint support.
File Viewer: Built-in support for PDFs and manuals.
