PanelView 5310 Graphic Terminal
SKU: 2713P-T10CD1-B
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2713P-T10CD1-B is a 10.4-inch touchscreen graphic terminal from Rockwell Automation's PanelView 5310 series, designed to work seamlessly with ControlLogix 5570/5580 and CompactLogix 5370/5380/5480 controllers over EtherNet/IP.
The "-B" suffix signifies a brandless bezel, making it suitable for OEM or private-label applications.
This device has a colour TFT LCD with a 4:3 aspect ratio and provides fine analogue resistive touch control.
It can support up to 100 user-defined displays and 4,000 Logix-based alerts and is written in Studio 5000 View Designer, which enables unified development with controller logic.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Display: 10.4" colour TFT LCD, 800 × 600 resolution.
Touchscreen: Analog resistive, rated for 1 million actuations.
Memory: 1 GB RAM, 1 GB non-volatile storage.
Ethernet: 1 × 10/100Base-T port (Auto MDI/MDI-X).
USB:
1 × USB 2.0 host port (Type A).
1 × USB 2.0 device port (Type B; future release).
SD Card Slot: Supports 1784-SD1, SD2, SDHC8, SDHC32.
Power Supply: 24V DC SELV/PELV compliant.
Battery: CR2032 lithium coin cell (Allen-Bradley #2711P-RY2032).
Backlight: LED, non-replaceable, ≥50,000 hours at 40 °C.
Environmental Ratings:
Operating Temp: 0–55 °C.
Humidity: 5–95% non-condensing.
Shock: 15 g (operating), 30 g (non-operating).
Vibration: 2 g peak at 57–500 Hz.
Certifications: RoHS, UL, CE.
