PanelView 5310 Graphic Terminal CC
SKU: 2713P-T10CD1-K
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2713P-T10CD1-K is a 10.4-inch industrial touchscreen HMI from Rockwell Automation's PanelView 5310 series, specifically intended for high-performance machine-level visualization and control.
It has a colour TFT LCD with analogue resistive touch that is designed to work with Logix-based controllers over EtherNet/IP.
This model has conformal coating (CC) on internal electronics, which improves protection against moisture, dust, and corrosive conditions, making it appropriate for demanding industrial applications like chemical processing, food manufacturing, and outdoor installations.
Buy currently uses Select Automation shop pricing and checkout.
Display & Touchscreen:
Screen Size: 10.4 inches.
Resolution: 800 × 600 pixels (SVGA).
Display Type: Colour TFT LCD.
Touchscreen: Analog resistive.
Actuation Rating: 1 million presses.
Operating Force: <100 g.
Backlight: LED, non-replaceable.
Backlight Life: ≥50,000 hours at 40 °C.
Memory & Storage:
RAM: 1 GB.
Non-volatile Storage: 1 GB available for user projects.
SD Card Slot: Supports 1784-SD1 (1 GB), SD2 (2 GB), SDHC8 (8 GB), SDHC32 (32 GB).
Connectivity:
Ethernet: 1 × 10/100Base-T, Auto MDI/MDI-X.
USB Ports:
1 × USB 2.0 host (Type A) for external storage.
1 × USB 2.0 device (Type B – future release).
Power & Battery:
Power Supply: 24V DC SELV/PELV compliant.
Battery: CR2032 lithium coin cell.
Battery Life: ≥4 years at 25 °C.
Clock Accuracy: ±2 minutes/month.
Environmental Ratings:
Conformal Coating: Yes (for corrosive environments).
Operating Temperature: 0–55 °C.
Humidity: 5–95% non-condensing.
Shock:
Operating: 15 g @ 11 ms.
Non-operating: 30 g @ 11 ms.
Vibration:
0.012 in peak-to-peak, 10–57 Hz.
2 g peak at 57–500 Hz.
Software & Integration:
Programming Software: Studio 5000 View Designer.
Controller Compatibility:
ControlLogix 5570/5580.
CompactLogix 5370/5380/5480.
Max Screens: 100 users defined.
Alarms: Up to 4,000 Logix-based alarms.
