PanelView 5310 Graphic Terminal CC
SKU: 2713P-T12WD1-K
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
A 12.1-inch widescreen touchscreen graphic terminal from the PanelView 5310 series, the 2713P-T12WD1-K has been improved using conformal coating (CC).
This coating protects internal components against moisture, dust, chemicals, and severe temperatures, making it perfect for use in demanding industrial situations.
It is intended for seamless connection with ControlLogix 5570/5580 and CompactLogix 5370/5380/5480 controllers via EtherNet/IP, with Studio 5000 View Designer serving as the development tool.
Buy currently uses Select Automation shop pricing and checkout.
Display & Touchscreen:
Screen Size: 12.1 inches (diagonal).
Resolution: 1280 × 800 pixels (WXGA).
Aspect Ratio: 16:10 widescreen.
Touch Technology: Analog resistive (rated for 1 million presses).
Backlight: LED, non-replaceable.
Life expectancy: ≥50,000 hours at 40 °C.
Processor & Memory:
RAM: 1 GB.
User Storage: 1 GB non-volatile memory for project files.
Screen Capacity: Up to 100 user-defined screens.
Alarm Capacity: Up to 4,000 Logix-based alarms.
Connectivity & Expansion:
Ethernet Port: 1 × 10/100Base-T (Auto MDI/MDI-X).
USB Ports:
1 × USB 2.0 Host (Type A).
1 × USB 2.0 Device (Type B – future release).
SD Card Slot: Supports 1784-SD1, SD2, SDHC8, SDHC32 cards.
Power & Battery:
Input Voltage: 24V DC SELV/PELV compliant.
Real-Time Clock Battery:
Type: CR2032 lithium coin cell.
Life: ≥4 years at 25 °C.
Accuracy: ±2 minutes/month.
Environmental Ratings:
Operating Temperature: 0 to 55 °C.
Storage Temperature: –25 to 70 °C.
Humidity: 5% to 95% non-condensing.
Shock Resistance:
Operating: 15 g @ 11 ms.
Non-operating: 30 g @ 11 ms.
Vibration Resistance: 2 g peak at 57–500 Hz.
Conformal Coating (CC):
Protects internal circuitry from:
Moisture.
Dust.
Chemicals.
Corrosive vapours.
Ideal for harsh industrial environments (e.g., food processing, mining, chemical plants).
