PanelView 5310 Graphic Terminal 12.1-in
SKU: 2713P-T12WD1
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2713P-T12WD1 is a 12.1-inch widescreen touchscreen graphic terminal from the Rockwell Automation PanelView 5310 series.
It is designed to integrate seamlessly with ControlLogix 5570/5580 and CompactLogix 5370/5380/5480 controllers via EtherNet/IP, utilizing Studio 5000 View Designer software.
This model has a WXGA resolution display with a 16:10 aspect ratio, which provides a big and crisp interface for machine-level visualization.
It can support up to 100 user-defined screens and 4,000 Logix-based alarms, as well as comprehensive diagnostics and real-time control.
Buy currently uses Select Automation shop pricing and checkout.
Display & Input:
12.1-inch colour TFT LCD.
Resolution: 1280 × 800 pixels (WXGA).
Aspect ratio: 16:10.
Analog resistive touchscreen (rated for 1 million presses).
LED backlight (non-replaceable, ≥50,000 hours at 40 °C).
Performance & Memory:
1 GB RAM.
1 GB non-volatile storage for user projects.
Supports up to 100 user-defined screens.
Supports up to 4,000 Logix-based alarms.
Connectivity:
1 × Ethernet port (10/100Base-T, Auto MDI/MDI-X).
1 × USB 2.0 host port (Type A).
1 × USB 2.0 device port (Type B; available in future release).
SD card slot (supports 1784-SD1, SD2, SDHC8, SDHC32).
Power & Battery:
Power input: 24V DC SELV/PELV compliant.
Battery: CR2032 lithium coin cell.
Life: ≥4 years at 25 °C.
Accuracy: ±2 minutes/month.
Environmental Ratings:
Operating temperature: 0–55 °C.
Storage temperature: –25 to 70 °C.
Humidity: 5–95% non-condensing.
Shock: 15 g @ 11 ms (operating), 30 g @ 11 ms (non-operating).
Vibration: 2 g peak at 57–500 Hz.
Certifications: RoHS, UL, CE.
