PanelView 5310 Graphic Terminal
SKU: 2713P-T6CD1-B
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2713P-T6CD1-B is a 6-inch touchscreen-only graphic terminal from the PanelView 5310 series, intended for machine-level visualization and control.
The "-B" suffix signifies a brandless bezel, which means it lacks the Allen-Bradley branding and is appropriate for OEM or private-label applications.
This model is strongly integrated with the ControlLogix 5570/5580 and CompactLogix 5370/5380/5480 controllers via EtherNet/IP, and it is developed in Studio 5000 View Designer, which provides unified development alongside controller logic.
Buy currently uses Select Automation shop pricing and checkout.
Display & Input:
Screen Size: 6-inch colour TFT LCD.
Resolution: 640 × 480 pixels (VGA).
Aspect Ratio: 4:3.
Touchscreen: Analog resistive (rated for 1 million actuations).
Backlight: LED, non-replaceable, ≥50,000 hours at 40 °C.
Memory & Performance:
RAM: 1 GB.
User Storage: 1 GB non-volatile memory.
Max Screens: 100 user-defined screens.
Alarms: Up to 4,000 Logix-based alarms (with Studio 5000 View Designer v5 and Logix Designer v32 or higher).
Connectivity:
Ethernet: 1 × 10/100Base-T (Auto MDI/MDI-X).
USB Ports:
1 × USB 2.0 host (Type A).
1 × USB 2.0 device (Type B – future release).
SD Card Slot: Supports 1784-SD1, SD2, SDHC8, SDHC32.
Power & Battery:
Power Input: 24V DC SELV/PELV compliant.
Battery: CR2032 lithium coin cell.
Life: ≥4 years at 25 °C.
Accuracy: ±2 minutes/month.
Environmental Ratings:
Operating Temperature: 0–55 °C.
Humidity: 5–95% non-condensing.
Shock Resistance:
Operating: 15 g @ 11 ms.
Non-operating: 30 g @ 11 ms.
Vibration Resistance: 2 g peak at 57–500 Hz.
Certifications: RoHS, UL, CE.
Functional Highlights:
HTML5-capable browser for IP camera streams and embedded web content.
Integrated diagnostics with message buffer and confirmation.
Compact size ideal for space-constrained panels.
Brandless bezel for OEM/private-label flexibility.
