PanelView 5310 Graphic Terminal CC
SKU: 2713P-T6CD1-K
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2713P-T6CD1-K is part of the PanelView 5310 series, which is intended for high-performance machine-level visualization.
The "-K" suffix denotes conformal coating (CC), a protective layer applied to inside circuitry to protect against moisture, dust, chemicals, and corrosion.
This makes it perfect for tough industrial applications such as food processing, mining, and outdoor installations.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Display: 6-inch colour TFT LCD, 640 × 480 resolution (VGA), 4: 3 aspect ratios.
Touchscreen: Analog resistive, rated for 1 million actuations.
Memory: 1 GB RAM, 1 GB non-volatile user storage.
Controller Support: ControlLogix 5570/5580, CompactLogix 5370/5380/5480.
Communication: 1 × 10/100Base-T Ethernet (Auto MDI/MDI-X).
USB Ports: 1 × USB 2.0 host (Type A), 1 × USB 2.0 device (Type B – future release).
SD Card Slot: Supports 1784-SD1, SD2, SDHC8, SDHC32.
Power Supply: 24V DC SELV/PELV compliant.
Battery: CR2032 lithium coin cell, 4-year life, ±2 min/month accuracy.
Environmental Protection: Conformal coating for enhanced resistance to corrosive atmospheres.
Operating Temp: 0–55 °C.
Certifications: RoHS, UL, CE, and others as of July 2025.
