PanelView 5310 Graphic Terminal CC
SKU: 2713P-T9WD1-K
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
A 9-inch widescreen touchscreen graphic terminal from Allen-Bradley's PanelView 5310 series, the 2713P-T9WD1-K has a branded bezel (the "K" suffix) and is improved with conformal coating (CC) for increased protection in challenging conditions.
It is designed to integrate seamlessly with ControlLogix 5570/5580 and CompactLogix 5370/5380/5480 controllers via EtherNet/IP, utilizing Studio 5000 View Designer software.
This terminal can support up to 100 user-defined panels and 4,000 Logix-based alarms, as well as enhanced diagnostics, gesture-based interactivity, and a streamlined design interface.
The conformal coating protects internal electronics from moisture, dust, and corrosive gasses, making it appropriate for harsh industrial environments.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Display:
9-inch WVGA TFT LCD.
Resolution: 800 × 480 pixels.
Analog resistive touchscreen (rated for 1 million presses).
LED backlight (non-replaceable, ≥50,000 hours at 40 °C).
Memory & Storage:
1 GB RAM.
1 GB non-volatile storage.
SD card slot (supports 1784-SD1, SD2, SDHC8, SDHC32 cards).
Connectivity:
1 × Ethernet port (10/100Base-T, Auto MDI/MDI-X).
1 × USB 2.0 host port (Type A).
1 × USB 2.0 device port (Type B, future release).
Power Supply:
24V DC (Safety Extra Low Voltage and Protected Extra Low Voltage compliant).
Battery:
CR2032 lithium coin cell.
Life: ≥4 years at 25 °C.
Accuracy: ±2 minutes/month.
Environmental Ratings:
Conformal Coating: Yes (CC).
Operating Temp: 0–55 °C.
Humidity: 5–95% non-condensing.
Shock: 15 g @ 11 ms (operating), 30 g @ 11 ms (non-operating).
Vibration: 2 g peak at 57–500 Hz.
Certifications: RoHS compliant.
