PanelView 5510 Graphic Terminal CC
SKU: 2715P-T7WD-K
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2715P-T7WD-K PanelView 5510 Graphic Terminal CC is a 7-inch touchscreen-only HMI from Allen-Bradley's PanelView 5000 series that features conformal coating (CC) for improved protection in tough industrial applications.
The "K" suffix signifies a branded bezel with the Allen-Bradley emblem.
Model: 2715P-T7WD-K.
Series: PanelView 5510.
Display Type: Touchscreen-only graphic terminal.
Conformal Coating: Protects internal circuitry from moisture, dust, and corrosive gases.
Software: Studio 5000 View Designer.
Controller Integration: ControlLogix 5570/5580 and CompactLogix 5370/5380/5480.
Lifecycle Status: Active.
Buy currently uses Select Automation shop pricing and checkout.
Display & Input:
Screen Size: 6.5-inch colour TFT LCD.
Resolution: 640 × 480 (VGA), 4:3 aspect ratio.
Touchscreen: Analog resistive, rated for 1 million actuations.
Backlight: LED, non-replaceable, ≥50,000 hours at 40 °C to half-brightness.
System Specs:
RAM: 1 GB.
Storage: 1 GB non-volatile memory for user projects.
Battery: CR2032 lithium coin cell.
Life: ≥4 years at 25 °C.
Accuracy: ±2 minutes/month.
Connectivity:
Ethernet Ports:
2 × 10/100Base-T (Auto MDI/MDI-X).
Supports DLR, linear, and star topologies.
USB Ports:
2 × USB 2.0 host (Type A).
1 × USB 2.0 device (Type B).
SD Card Slot:
Supports external storage via 1784-SDx cards.
Features & Capabilities:
Screens: Up to 500 user-defined screens.
Alarms: Up to 4,000 Logix-based alarms (with View Designer v5 and Logix Designer v32 or higher).
Diagnostics: Built-in message system with buffer and confirmation.
Web Browser: HTML5-capable for IP camera streams and embedded content.
Touch Gestures: Supports tap, swipe, and runtime interactions.
AS-Interface Safety Protocol Support: Included.
Environmental Ratings:
Operating Temp: 0–55 °C.
Storage Temp: –25 to +70 °C.
Humidity: 5–95% non-condensing.
Shock: 15 g @ 11 ms (operating), 30 g @ 11 ms (non-operating).
Vibration: 2 g peak at 57–500 Hz.
Certifications: RoHS compliant.
