Toggle lever valve with idle return, L-3-M5

Specifications • Valves, mechanically actuated, Toggle lever valve with idle return • Valve function 3/2-way, closed, monostable • Type of actuation Mechanical • Standard nominal flow rate (standardised to DIN 1343) 80 l/min • Pneumatic working port M5 • Operating pressure -0.95 bar ... 8 bar • Design Poppet seat • Nominal size 2 mm • Type of piloting Direct • Symbol 00991096 • Operating medium Compressed air to ISO 8573-1:2010 [-:-:-] • LABS (PWIS) conformity VDMA24364-B1/B2-L • Ambient temperature -10 °C ... 60 °C
