One-way flow control valve, GGO-1/4-3/8

Specifications • One-way flow control valve • Valve function One-way flow control function • Pneumatic connection, port 1 G1/4 • Pneumatic connection, port 2 G1/4 • Type of actuation Mechanical • Adjustment component Roller lever • Type of mounting With through-hole • Standard nominal flow rate in flow control direction 950 l/min • Standard nominal flow rate in blocked direction 1150 l/min • Operating pressure 0.03 bar ... 8 bar • Operating pressure 0.43 psi ... 116 psi • Ambient temperature -10 °C ... 60 °C • Material housing Wrought aluminium alloy • Mounting position optional
