Optical Photoelectric Limit Switch sensor
SKU: 3DP-0127-P01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The Optical Photoelectric Limit Switch Sensor is a non-contact position detection module that detects when an object interrupts the light beam that is going through the optical slot using an infrared emitter and receiver.
Unlike mechanical limit switches, optical sensors have no physical wear points, resulting in increased dependability, faster response times, and better positioning precision.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Sensor Type: Optical Photoelectric End stop Sensor.
Detection Method: Infrared beam interruption.
Operating Voltage: 3.3V – 5V DC.
Output Signal: Digital output (SIG).
Interface: 3-pin connector.
Pin Configuration:
VCC
GND
SIG
Mounting Type: PCB mounting with dual fixing holes.
Connection Type: JST-style connector.
Indicator: Onboard status LED.
Detection Speed: High-speed response suitable for motion control.
Operating Temperature: -10°C to +60°C.
Board Colour: Black PCB.
Features:
Non-contact operation eliminates mechanical wear.
High repeatability and positioning accuracy.
Fast switching response.
Low power consumption.
Compact design for easy installation.
Resistant to vibration and mechanical fatigue.
Typical Applications:
3D printer X, Y, and Z axis end stops
CNC machine homing switches
Laser engravers
Robotics position sensing
Automated machinery
Linear motion systems
