GT2 BELT 6MM 160
SKU: 3DP-0328-DS1
Sold by Select Automation
Final price R 32.07
R 27.89 excl. VAT
Availability: In Stock (2 on hand)
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The GT2 160mm closed-loop timing belt (6mm wide) is a short, durable motion component ideal for compact mechanical systems. Its rounded tooth profile minimizes slippage and backlash, making it perfect for short-path applications such as Z-axis lifts, small gantry systems, or robotics joints. Despite its small size, the fiberglass-reinforced neoprene construction provides strength and durability under continuous use.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Type: GT2 closed-loop timing belt
Length: 160mm
Width: 6mm
Pitch: 2mm (distance between teeth)
Number of Teeth: 80
Tooth Profile: Rounded (optimized for GT2 pulleys, reduces backlash)
Material: Neoprene rubber with fiberglass reinforcement
Tooth Height: ~0.75mm
Profile Height: ~1.38mm
Color: Black
Applications:Compact 3D printers (short axis or Z-axis motion systems)CNC machines with limited travel distancesLaser cutters with small framesRobotics and automation systems requiring very short closed-loop belts
