Pushbutton, 16 mm, round, plastic, black, pushbutton, raised
SKU: 3SB2000-0LB01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Pushbutton, 16 mm, circular, plastic, black, and raised. SIRIUS 3SB2 pushbuttons allow you to switch and control electrical loads.
The industry-standard 3SB2 pushbuttons and indicator lights are modularly designed and have been tested in practice.
Their tiny size makes them ideal for small control panels.
They are highly functional and rugged and meet the IEC/EN 60947-5-1 and 60947-5-5 standards.
They may be put at a high packing density without the use of any special tools.
Holder and contact blocks separately.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Brand name: SIRIUS.
Product designation: Pushbuttons.
Design of the product: Single device round.
Product designation: 3SB2.
Number of command points: 1.
Material of holder: Plastic.
Protection class: IP65.
Actuator:
Design of the actuating element: Pushbutton.
Principal of operation of the actuating element: Momentary contact type.
Colour of the actuating element: Black.
Material of the actuating element: Plastic.
Shape of the actuating element: Raised pushbutton.
Outer diameter of the actuating element: 19 mm.
Type of unlocking device: Without.
Number of switching positions: 2.
Front ring:
Product component front ring: Yes.
Design: Standard.
Material: Plastic.
Colour: Black.
Ambient Temperature:
During operation: -25 - +70°C.
During storage: -40 - +80°C.
Installation / mounting / dimensions:
Fastening method: Front plate mounting.
Shape of the installation opening: Round.
Mounting diameter: 16 mm.
Mounting height: 12 mm.
Installation width: 19 mm.
Installation depth: 50 mm.
