Illuminated pushbutton, 16 mm, round, plastic, red, pushbutton, raised
SKU: 3SB2001-0LC01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIRIUS 3SB2 illuminated pushbuttons for switching and managing electrical loads are 16 mm circular, plastic, red, and elevated.
The industry-standard 3SB2 pushbuttons and indicator lights are modularly designed and have been tested in practice.
Their tiny size makes them ideal for small control panels.
They are highly functional and rugged and meet the IEC/EN 60947-5-1 and 60947-5-5 standards.
They may be put at a high packing density without the use of any special tools.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Brand name: SIRIUS.
Product designation: Illuminated pushbuttons.
Design of the product: Single device round.
Product type designation: 3SB2.
Number of command points: 1.
Protection class: IP65.
Material of the holder: Plastic.
Actuator:
Design of the actuating element: Illuminated pushbutton.
Principal of operation of the actuating element: Momentary contact type.
Product extension optional light source: Yes.
Colour of the actuating element: Red.
Material of the actuating element: Plastic.
Shape of the actuating element: Raised pushbutton.
Outer diameter of the actuating element: 19 mm.
Type of unlocking device: Without.
Number of switching positions: 2.
Front ring:
Product component front ring: Yes.
Design of the front ring: Standard.
Material of the front ring: Plastic.
Colour of the front ring: Black.
Ambient Temperature:
During operation: -25 - +70°C.
During Storage: -40 - +80°C.
Installation / Mounting / Dimensions:
Fastening method: Front plate mounting.
Shape of the installation opening: Round.
Mounting diameter: 16 mm.
Mounting height: 12 mm.
Installation width: 19 mm.
Installation depth: 50 mm.
