Selector switch, 16 mm, round, plastic, white, 3 switch positions I-O-II, latching, Actuating angle 2 x 62 degree, 1 NO, 1 NO
SKU: 3SB2210-2DG01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Selector switch, 16 mm, round, plastic, white, three switch positions I-O-II, latching.
Actuating Angle 2 x 62 degrees, 1 NO. SIRIUS 3SB2 selector switches allow you to switch and manage electrical loads.
The industry-standard 3SB2 pushbuttons and indicator lights are modularly designed and have been tested in practice.
Their tiny size makes them ideal for small control panels.
They are highly functional and rugged and meet the IEC/EN 60947-5-1 and 60947-5-5 standards.
They may be put at a high packing density without the use of any special tools.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product Brand name: SIRIUS.
Product designation: Selector switches.
Design of the product: Complete unit round.
Product type designation: 3SB2.
Number of command points: 1.
Type of voltage of the operating voltage: AC/DC.
Operating voltage rated value: 5 – 250V.
Protection class: IP65.
Material of the holder: Plastic.
Actuator:
Design of the actuating element: Selector switch.
Principal of operation of the actuating element: Latching.
Product extension optional light source: no.
Colour of the actuating element: White.
Material of the actuating element: Plastic.
Shape of the actuating element: Rotate-to-unlatch mechanism.
Number of switching positions: 3.
Front ring:
Product component front ring: Yes.
Design of the front ring: Standard.
Material of the front ring: Plastic.
Colour of the front ring: Black.
Contact block/lamp holder:
Number of lamp holders: 0.
Number of switching elements: 2.
Auxiliary circuit:
Number of NC contacts for auxiliary contacts: 0.
Number of NO contacts for auxiliary contacts: 2.
Number of CO contacts for auxiliary contacts: 0.
Operational current at AC – 12:
At 24V rated value: 10A.
At 60V rated value: 10A.
At 110V rated value: 10A.
At 230V rated value: 10A.
Operational current at AC – 15:
At 24V rated value: 4A.
At 110V rated value: 4A.
At 230V rated value: 4A.
Operational current at DC – 12:
At 24V rated value: 6A.
At 60V rated value: 5A.
At 110V rated value: 2.5A.
At 230V rated value: 1A.
Operational current at DC -13:
At 24V rated value: 3A.
At 60V rated value: 1.2A.
At 110V rated value: 0.7A.
At 230V rated value: 0.3A.
Connections/Terminals:
Type of electrical connection: Tab terminals.
Tightening torque of the screws in the bracket maximum: 0.4 N-m.
Ambient Temperature:
During operation: -25 - +70°C.
During Storage: -40 - +80°C.
Installation / Mounting / Dimensions:
Fastening method: Front plate mounting.
Shape of the installation opening: Round.
Mounting diameter: 16 mm.
Mounting height: 17 mm.
Installation width: 19 mm.
Installation depth: 50 mm.
