Illuminated pushbutton, 16 mm, round, plastic, clear, pushbutton, flat, 1 NO, Lampholder W2 x 4.6 d, with incandescent lamp 24 V
SKU: 3SB2226-0AH01
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
This illuminated pushbutton is 16 mm round, made of plastic, clear, and flat. It has a lamp holder measuring W2 x 4.6 d and a 24 V incandescent light.
Product brand name: SIRIUS.
Product designation: Illuminated pushbuttons.
Design of the product: Complete unit round.
Product type designation: 3SB2.
Buy currently uses Select Automation shop pricing and checkout.
General technical data:
Product function:
Positive opening: No.
EMERGENCY STOP function: No.
Product component light source: Yes.
Type of voltage of the operating voltage: AC/DC.
Protection class IP: IP65.
Vibration resistance according to IEC 60068-2-6: 20 ... 200 Hz: 5g.
Operating frequency maximum: 1 000 1/h.
Mechanical service life (operating cycles) typical: 3 000 000.
Reference code according to IEC 81346-2: S.
Weight: 0.025 kg.
Operating voltage rated value: 5 ... 60 V.
Ambient conditions:
Ambient temperature:
During operation: -25 ... +60 °C.
During storage: -40 ... +80 °C.
Environmental category during operation according to IEC 60721: 3K6.
