Electronic module for ID key-operated switch, black
SKU: 3SU1400-1GD10-1AA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Electronics module IO-Link for ID key-operated switch, with 5 pre-programmed electronic switches.
Controller and RFID authentication of the switching function, black, operating voltage 24 V DC, screw terminal.
For front plate mounting, for industrial application in control cabinets and machines.
Electronic module for ID key-operated switches SIRIUS ACT for connecting the ID key-operated switch.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Product brand name: SIRIUS ACT.
Product designation: Electronic module for ID key-operated switches.
Product type designation: 3SU1.
Number of LEDs: 4.
Insulation voltage rated value: 30 V.
Type of voltage:
Of the operating voltage: DC.
Of the input voltage: DC.
Consumed current maximum: 49 mA.
Protection class: IP20, clamping screw tightened.
Operating voltage:
Rated value: 18 - 30 V.
At DC rated value: 24 V.
Auxiliary circuit:
Number of NC contacts for auxiliary contacts: 0.
Number of NO contact for auxiliary contacts: 5.
Inputs/Outputs:
Number of digital inputs: 0.
Number of digital outputs: 5.
Output voltage at digital outputs at DC rated value: 23.5 V.
Output current per output: 250 mA.
Type of electrical connection: Screw terminal.
Ambient temperature:
During operation: -25 - +70°C.
During storage: -40 - +80°C.
Installation/Mounting/Dimensions:
Fastening method of modules and accessories: Front plate mounting.
Height: 36 mm.
Width: 50 mm.
Depth: 36.4 mm.
Required spacing with side-by-side mounting:
Forwards: 100 mm.
Backwards: 100 mm.
Upwards: 100 mm.
Downwards: 100 mm.
At the side: 100 mm.
