U-1000dc V/METER MOD 400-1200VDC
SKU: 4829 0154
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Digiware DIRIS DC:
The best option for metering usage is the multi-circuit power monitoring device, or DIRIS Digiware.
Measuring and keeping an eye on the electrical energy quality for use in commercial and industrial settings.
The complete system's DC voltage is measured using the DIRIS Digiware U-31/32dc module.
With a direct connection, it can measure up to 180 VDC, making it compatible with nominal voltages that are typically 24 or 48 VDC.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
DC voltage adaptor.
SERIES DC Digiware.
MODEL U1000DC.
RANGE 400...1200 VDC.
DESCRIPTION Modular voltage adaptor metering module.
MODULE WIDTH (MM) 53.
Qualities:
Precision according to IEC 61557-12 standard (Class 0.5).
Implementation in 25% less time than current metering technologies.
Installing current sensors and measuring modules where the load is closest to the source.
Has independent current inputs that allow it to monitor several circuits with a single current measuring module.
Small and adaptable design: ideal for both new and old installations, even panels with limited room.
Modules for measuring voltage:
Precision of voltage measurement: Class 0.5.
For the entire system, there is only one voltage measurement point.
The system is compatible with all voltage levels up to 1650 VDC thanks to voltage adapters.
A comprehensive, focused solution for voltage monitoring, metering, and voltage quality analysis.
The RJ45 bus lets you supply electricity to all connected devices and evaluate voltage.
