DIRIS D50 DISPLAY + MODBUS TCP

Specifications: SERIES Digiware. MODEL D-50. DESCRIPTION Centralisation unit with multi-point display + Modbus TCP. MOUNTING Panel. COMMUNICATION RS485. DIMENSIONS (MM) 96 X 96. Qualities: Precision according to IEC 61557-12 standard (Class 0.5). Implementation compared to current metering technologies in a fifth of the time. At the location nearest to the load, measurement modules and current sensors are installed. Has independent current inputs, allowing it to monitor many circuits with a single current measuring module. Compact and adaptable design: ideal for both new and old installations, even those with space-constrained panels. D-40/50/70 Data centralization and visualization: High-definition LCD panel. 24 VDC power supply is necessary. Data from the voltage and current modules displayed locally. Direct access to the circuit selection device setup is provided by keys on the front face.
