FLEXHA 5000 Adapter Base
SKU: 5015-A2AXT
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The FLEXHA 5000TM I/O system, which is intended for high-availability, fault-tolerant industrial automation, uses the 5015-A2AXT adapter base.
It acts as the primary mounting and connection platform for several FLEXHA 5000 components, allowing for modular and scalable I/O setups.
Key Features:
Supports Duplex Configuration:
Enables high availability with redundant adapters and power conditioners.
Component Capacity:
Holds up to:
2 × Power Conditioners (e.g., 5015-PB100FTXT).
2 × EtherNet/IP Adapters (e.g., 5015-AENFTXT).
2 × Media Landing Cards.
2 × Backplane Interface Modules.
2 × MOD Power Removable Terminal Blocks (RTBs).
16 × Diagnostic Inputs.
Mounting:
Installed on an extruded mounting plate (e.g., 5015-MPxxxxXT).
Must be mounted horizontally (not flat facing upward).
System Integration:
Works with FLEXHA 5000 modules for fault tolerant I/O.
Supports shielded wiring for EMI mitigation.
Lifecycle Status: Active.
Certified as of July 2025 (check product label for specific certifications).
Buy currently uses Select Automation shop pricing and checkout.
Mechanical & Mounting:
Horizontal mounting orientation only (not flat facing upward).
Requires installation on an extruded mounting plate (e.g., 5015-MPxxxxXT).
Minimum enclosure depth: 203 mm (8 inches).
Designed for modular, scalable I/O configurations.
Electrical & Connectivity:
Supports duplex configuration for high availability.
Requires shielded wiring for EMI mitigation.
Interfaces with FLEXHA 5000 backplane modules.
Compatible with EtherNet/IP DLR port configurations.
Module Capacity:
Holds up to:
2 × EtherNet/IP Adapters (e.g., 5015-AENFTXT).
2 × Power Conditioners (e.g., 5015-PB100FTXT).
2 × Media Landing Cards.
2 × Backplane Interface Modules.
2 × MOD Power Removable Terminal Blocks (RTBs).
16 × Diagnostic Inputs.
Certifications & Compliance:
UL Listed for Class I, Division 2, Groups A, B, C, D hazardous locations.
Certified as of July 20, 2025 (check product label for details).
