FLEXHA 5000 Media Landing Card
SKU: 5015-MLTRXT
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5015-MLTRXT Media Landing Card is compatible with Allen-Bradley's FLEXHA 5000™ I/O platform.
It functions as the network interface module, allowing high-speed, redundant EtherNet/IP connection between FLEXHA 5000 I/O modules and the overall control system.
With two RJ45 connections and extended temperature resistance, it's designed for maximum availability in harsh industrial applications.
Key Features:
Dual RJ45 Ethernet Ports for redundant media support.
Status LEDs for link, activity, and diagnostics.
XT (Extended Temperature) rating for harsh environments.
Plug-in Design for easy installation and maintenance.
Supports High Availability architectures in industrial automation.
Buy currently uses Select Automation shop pricing and checkout.
Technical Specifications:
Catalogue Number: 5015-MLTRXT.
Product Type: Media Landing Card.
System Compatibility: FLEXHA 5000™ I/O platform.
Ports:
2 × RJ45 Ethernet ports.
Supports redundant EtherNet/IP media paths.
Indicators:
LED lights for link status, activity, and diagnostics.
Mounting:
Plug-in module with screw retention.
Compact form factor for FLEXHA 5000 bases.
Environmental Ratings:
Temperature Range: –40 °C to +70 °C (XT – Extended Temperature).
Humidity: 5% to 95% non-condensing.
Shock & Vibration: Meets industrial-grade standards.
Ingress Protection: Depends on enclosure; module itself is not IP-rated.
Certifications & Compliance:
CE – European Union.
UKCA – United Kingdom.
RCM – Australia/New Zealand.
FM Approved – Hazardous locations.
IECEx – Global explosive atmospheres.
ABS – Marine and offshore applications.
Functional Capabilities:
Network Protocol: EtherNet/IP.
Redundancy Support: Yes – dual media paths for high availability.
System Role: Provides media interface for FLEXHA 5000 adapters and I/O modules.
Diagnostics: Real-time LED indicators for communication health.
