FLEXHA 5000 RTB Duplex
SKU: 5015-RTBRPXT
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5015-RTBRPXT is a Removable Terminal Block (RTB) developed for Duplex configurations within the FLEXHA 5000™ I/O system.
It enables High Availability (HA) with fault-tolerant I/O modules and redundant EtherNet/IP™ adapter pairs.
This RTB guarantees dependable operation in challenging industrial settings because it is designed for XT (Extended Temperature) environments.
Key features:
Duplex Support: Enables two I/O modules to run in parallel for redundancy.
XT Rated for extended temperature ranges (-40°C to +70°C).
The Field Wiring Interface simplifies installation and maintenance.
Hot-swappable: Modules can be replaced without damaging the wiring.
Robust Design: Designed for use in hostile environments and mission-critical applications.
Certifications include CE, UKCA, FM, IECEx, RCM, and ABS.
Buy currently uses Select Automation shop pricing and checkout.
General Specifications:
Catalogue Number: 5015-RTBRPXT.
Product Type: Removable Terminal Block (RTB).
System: FLEXHA 5000™ I/O.
Configuration: Duplex (supports redundant I/O modules).
Mounting: Directly attaches to I/O modules.
Hot-Swappable: Yes — allows module replacement without disturbing wiring.
Field Wiring Interface: Simplifies installation and maintenance.
Terminal Type: Typically screw-type or spring clamp (varies by module).
Wire Size Range: 0.25–2.5 mm² (AWG 24–12).
Number of Terminals: Depends on module (commonly 16–32 points).
Environmental Ratings:
Temperature Range: –40 °C to +70 °C (XT-rated for extended environments).
Humidity: 5% to 95% non-condensing.
Vibration Resistance: Complies with IEC 60068-2-6.
Shock Resistance: Complies with IEC 60068-2-27.
Ingress Protection: IP20 (when installed in enclosure).
Certifications & Compliance:
CE.
UKCA.
FM Approved.
IECEx.
RCM (Australia/New Zealand).
ABS (Marine & Offshore).
