Compact GuardLogix SIL3 1.0/0.5M Motion
SKU: 5069-L310ERMS3
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5069-L310ERMS3 is a high-performance Compact GuardLogix 5380 controller for SIL3/PLe safety applications that includes motion control.
It has 1.0 MB of regular memory and 0.5 MB of safety memory, making it suited for medium-sized machines that need both coordinated motion and functional safety.
This controller offers integrated motion over EtherNet/IP, which allows for precise control of servo motors and axes.
It has dual embedded EtherNet/IP ports that use the Device Level Ring (DLR) topology for fault-tolerant networking.
The "S3" designation indicates that it can handle SIL3 safety functions, making it suitable for applications such as robotics, packaging, and material handling where safety and performance are critical.
Programming is done using Studio 5000 Logix Designer, which provides a single environment for standard, safety, and motion logic.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Standard Memory: 1.0 MB.
Safety Memory: 0.5 MB.
Safety Rating: SIL3, PL e.
Motion Support:
Integrated motion over EtherNet/IP.
Supports coordinated motion control.
EtherNet/IP Ports:
2 × embedded ports.
Support for DLR and linear topologies.
Backplane Bandwidth: 50 Mbps.
Real-Time Clock: Integrated.
SD Card Slot: Optional (for backup and restore).
Power Supply: 24 VDC input.
Programming Software: Studio 5000 Logix Designer.
Environmental Ratings:
Operating Temperature: –20°C to +65°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 2g.
