Compact GuardLogix SIL3 1.0/0.5M Motion
SKU: 5069-L310ERMS3K
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5069-L310ERMS3K is a high-performance Compact GuardLogix 5380 controller for SIL3/PLe safety applications that includes motion control.
It has 1.0 MB of standard memory and 0.5 MB of safety memory, making it ideal for medium-sized machines that need both coordinated motion and functional safety.
The "K" suffix denotes conformal coating, which shields the controller's internal circuitry from moisture, dust, and corrosive environments—ideal for tough industrial applications such as food processing, chemical manufacture, or outdoor installations.
This controller enables motion over EtherNet/IP, which allows for synchronized control of servo drives and axes.
It has two inbuilt EtherNet/IP ports and Device Level Ring (DLR) functionality for fault-tolerant networking.
Programming is done using Studio 5000 Logix Designer, which provides a unified platform for standard, safety, and motion logic.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Standard Memory: 1.0 MB.
Safety Memory: 0.5 MB.
Safety Rating: SIL3, PL e.
Motion Support:
Integrated motion over EtherNet/IP.
Supports coordinated motion control.
Conformal Coating: Yes (K-rated variant).
EtherNet/IP Ports:
2 × embedded ports.
Support for DLR and linear topologies.
Backplane Bandwidth: 50 Mbps.
Real-Time Clock: Integrated.
SD Card Slot: Optional (for backup and restore).
Power Supply: 24 VDC input.
Programming Software: Studio 5000 Logix Designer.
Environmental Ratings:
Operating Temperature: –20°C to +65°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 2g.
