CompactLogix 2MB Enet Motion Controller
SKU: 5069-L320ERMK
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5069-L320ERMK is a ruggedized version of the CompactLogix 5380 controller that supports high-performance control and Integrated Motion via EtherNet/IP.
It has 2 MB of user memory and can support up to 16 motion axes, making it appropriate for medium-sized motion applications including packaging, robotics, and material handling.
The "ERM" suffix denotes support for EtherNet/IP with Integrated Motion, whereas the "K" suffix implies conformal coating, which protects the controller's internal circuitry from moisture, dust, and corrosive environments.
This makes the L320ERMK ideal for severe industrial environments such as food processing, mining, and outdoor applications.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
User Memory: 2 MB.
Controller Series: CompactLogix 5380.
Motion Support: Integrated Motion over EtherNet/IP.
Maximum Axes: 16 axes.
Backplane Bandwidth: 50 Mbps.
Ethernet Ports:
2 × EtherNet/IP ports.
Embedded switch with Device Level Ring (DLR) support.
Real-Time Clock: Integrated.
SD Card Slot: Optional (for backup and restore).
Power Supply: 24 VDC input.
Conformal Coating: Yes (“K” variant).
Programming Software: Studio 5000 Logix Designer.
Environmental Ratings:
Operating Temperature: –20°C to +65°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 2g.
