Compact GuardLogix SIL3 2.0/1.0M Motion
SKU: 5069-L320ERMS3
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5069-L320ERMS3 is a high-capacity Compact GuardLogix 5380 controller for advanced SIL3/PLe-rated safety applications that includes motion control.
It has 2.0 MB of ordinary memory and 1.0 MB of safety memory, making it suitable for big and sophisticated machines that require both coordinated motion and functional safety.
This controller enables motion over EtherNet/IP, allowing for simultaneous control of numerous servo axes.
It has two inbuilt EtherNet/IP ports and Device Level Ring (DLR) functionality for fault-tolerant networking.
The "S3" designation verifies its eligibility for SIL3 safety functions, which are approved for usage in critical safety situations such as robotics, packaging, and high-speed production.
Programming is done with Studio 5000 Logix Designer, which provides a unified platform for standard, safety, and motion logic development.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Standard Memory: 2.0 MB.
Safety Memory: 1.0 MB.
Safety Rating: SIL3, PL e.
Motion Support:
Integrated motion over EtherNet/IP.
Supports coordinated motion control.
EtherNet/IP Ports:
2 × embedded ports.
Support for DLR and linear topologies.
Backplane Bandwidth: 50 Mbps.
Real-Time Clock: Integrated.
SD Card Slot: Optional (for backup and restore).
Power Supply: 24 VDC input.
Programming Software: Studio 5000 Logix Designer.
Environmental Ratings:
Operating Temperature: –20°C to +65°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 2g.
