Compact GuardLogix SIL2 5.0/2.5M
SKU: 5069-L350ERS2
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5069-L350ERS2 is a mid-to-high performance Compact GuardLogix 5380 controller intended for applications that require both standard control and integrated safety up to SIL 2 / PLd.
With 5.0 MB of ordinary user memory and 2.5 MB of safety memory, it's ideal for systems requiring dependable safety and motion control, such as packaging, material handling, and coordinated automation.
This controller supports Integrated Motion over EtherNet/IP for up to 16 axes and includes two embedded EtherNet/IP ports with Device Level Ring (DLR) support for fault-tolerant networking.
It is programmed using Studio 5000 Logix Designer, which allows for the construction of both safety and standard logic on a single platform.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Standard User Memory: 5.0 MB.
Safety Memory: 2.5 MB.
Safety Rating: SIL 2 / PLd (IEC 61508, ISO 13849-1).
Motion Support: Integrated Motion over EtherNet/IP.
Maximum Axes: Up to 16 axes.
Communication Ports:
2 × EtherNet/IP ports (embedded switch, DLR support).
I/O Compatibility: Compact 5000 I/O modules.
Backplane Communication Speed: 50 Mbps.
Real-Time Clock: Integrated.
SD Card Support: Optional for backup and restore.
Conformal Coating: Yes.
Power Requirements: 24 VDC input.
Programming Software: Studio 5000 Logix Designer.
Environmental Ratings:
Operating Temperature: –20°C to +65°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 2g.
