5094 Ethernet Adapter 16 Modules SFP
SKU: 5094-AEN2SFPR
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5094-AEN2SFPR is a high-performance EtherNet/IP™ adapter from Rockwell Automation's FLEX 5000™ I/O platform.
It connects to 16 I/O modules, including standard and safety-rated varieties, into a scalable, distributed control system.
This adapter's dual SFP (Small Form-factor Pluggable) ports provide versatile network setups using either fibre or copper transceivers.
This makes it excellent for industrial settings that require high-speed communication, network redundancy, and dependable performance.
Buy currently uses Select Automation shop pricing and checkout.
Electrical Specifications:
Main Power Supply: 18–32V DC.
Nominal Current: 1730 mA.
Inrush Current: 5700 mA for 100 ms.
Backplane Power: 15V DC, 1800 mA.
Power Consumption: Depends on connected modules (up to 16 supported).
Network & Communication:
EtherNet/IP™ Ports: 2 × SFP slots.
Supports fibre or copper SFP transceivers.
Network Topologies Supported:
Star.
Linear.
Device Level Ring (DLR).
Parallel Redundancy Protocol (PRP).
Data Rate: 1 Gbps.
Concurrent Communication: Supported for safety I/O modules.
Module Capacity & Compatibility:
Supported Modules: Up to 16 FLEX 5000 I/O modules.
Safety I/O Support: Yes (firmware v3.011 or later).
Hot-Swap Capability: RIUP (Removal and Insertion Under Power).
Environmental Ratings:
Operating Temperature: –40 °C to +70 °C.
Storage Temperature: –40 °C to +85 °C.
Humidity: 5% to 95% non-condensing.
Shock & Vibration: IEC 60068-2 compliant.
Certifications: ATEX, IECEx, UL, CE (varies by region and date).
Physical Characteristics:
Mounting: DIN rail or FLEX 5000 base.
Dimensions: Compact form factor (exact dimensions vary by base).
Status Indicators: LED diagnostics for power, network, and module health.
