5094 Ethernet Adapter 8 Modules SFP
SKU: 5094-AENSFPR
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 5094-AEN2SFPR is a high-performance EtherNet/IP™ adapter from Rockwell Automation's FLEX 5000™ I/O platform. It connects up to 16 I/O modules, including standard and safety-rated varieties, into a scalable, distributed control system.
This adapter's dual SFP (Small Form-factor Pluggable) ports provide versatile network setups using either fibre or copper transceivers.
This makes it excellent for industrial settings that require high-speed communication, network redundancy, and dependable performance.
Dimensions:
Width: 94 mm.
Height: 92.7 millimetres.
Depth: 96.5 mm.
Mounting options include DIN rail or FLEX 5000 terminal base.
Hot-Swap Support: Yes (RIUP - Removal and Insertion Under Power).
LED Indicators for power, network status, and diagnostics.
Buy currently uses Select Automation shop pricing and checkout.
Technical Features:
Supports EtherNet/IP™ protocol for high-speed industrial communication.
Accommodates up to 8 FLEX 5000™ I/O modules.
Equipped with 2 SFP ports for flexible media (fiber or copper).
Network speed: 1 Gbps full duplex.
Compatible with DLR, star, and linear topologies.
Configurable via Studio 5000 Logix Designer®.
Hot-swap capable (RIUP – Removal and Insertion Under Power).
LED indicators for power, network, and module status.
Power & Electrical:
Input voltage: 18–32 V DC.
Nominal current draw: ~1730 mA.
Inrush current: ~5700 mA for 100 ms.
Backplane power: 15 V DC @ 1800 mA.
Environmental Ratings:
Operating temperature: –40 °C to +70 °C.
Storage temperature: –40 °C to +85 °C.
Humidity: Up to 95% non-condensing.
Corrosion resistance: ISA S71.04 G3 compliant.
Certifications: UL, CE, ATEX, IECEx.
Physical Dimensions:
Width: 94 mm.
Height: 92.7 mm.
Depth: 96.5 mm.
Mounting: DIN rail or FLEX 5000 terminal base.
Approximate weight: ~0.5 kg.
