Sealing cap, CV-PK-6-B

Specifications • Sealing cap CV, Sealing cap for plastic tube fittings and barbed connectors • Size of pack 10 • Temperature-dependent operating pressure -0.095 MPa ... 1 MPa • Temperature-dependent operating pressure -0.95 bar ... 10 bar • Temperature-dependent operating pressure -13.775 psi ... 145 psi • Operating medium Compressed air to ISO 8573-1:2010 [7:-:-] • LABS (PWIS) conformity VDMA24364-B2-L • Ambient temperature -10 °C ... 80 °C • Pneumatic connection, port 1 For tubing outer diameter of 8 mm, For barbed fitting I.D. 6 mm with union nut • Note on materials RoHS-compliant • Material cap TPE-U(PU)
