30A 2 CHANGEOVER 66 SERIES HIGH POWER RELAY 110VDC
SKU: 668291100000
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
High power 2 pole relays in 66 series:
Voltages of AC and DC coils.
Fasten 250 termination (6.3 x 0.8 mm).
8 mm, 6 kV (1.2/50 ¼) coil-contacts, isolation.
Two-pole switch contacts 10A NC - 30A NO to EN60335-1, reinforced insulation between coil and connections.
Buy currently uses Select Automation shop pricing and checkout.
SERIES 66:
CURRENT: 30A.
DESCRIPTION: Plug-in industrial power relay.
CONTACT CONFIGURATION: 2 changeovers.
COIL VOLTAGE: 110 VDC.
DIMENSIONS (MM): 31 x 51.5 x 33.5.
