SIMATIC ET 200pro 16DI 24 V DC
SKU: 6ES7141-4BH00-0AA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC DP electronic module for ET 200 PRO 16 DI 24 V DC includes diagnostics, bus module, and connection module (IO 6ES7194-4CB50-0AA0), which can be ordered separately.
General information:
Product function:
Isochronous mode: No.
Buy currently uses Select Automation shop pricing and checkout.
Supply voltage:
Rated value (DC): 24 V.
Reverse polarity protection: Yes; Against destruction; encoder power supply outputs applied with reversed polarity.
Input current:
from supply voltage 1L+, max.: 30 mA.
from backplane bus 3.3 V DC, max.: 20 mA.
Power loss:
Power loss, typ.: 3 W.
Address area:
Address space per module:
Address space per module, max.: 2 byte.
Digital inputs:
Number of digital inputs: 16.
Input characteristic curve in accordance with IEC 61131, type 1: Yes.
Dimensions:
Width: 45 mm.
Height: 130 mm.
Depth: 35 mm.
Weights:
Weight, approx.: 140 g.
