SIMATIC ET 200pro 4DQ 24 V DC/2 A HF
SKU: 6ES7142-4BD00-0AB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC DP, Electronic modules for ET 200 PRO 4 DO 24 V DC, 2.0A High Feature, Channel diagnostics; short-circuit and wire break; includes bus module, Connection module IO 6ES7194-4.00-0AA0 (order separately).
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Supply voltage for load voltage 2L+:
Rated value (DC): 24 V.
Short-circuit protection: per channel, electronic.
Reverse polarity protection: against destruction; load increasing.
Input current:
From load voltage 2L+ (without load), max: 40 mA.
From backplane bus 3.3 V DC, max: 30 mA.
Typical power loss: 2.5 W.
Digital outputs:
Number of digital outputs: 4.
Short-circuit protection.
Response threshold: 2.8 A.
Limitation of inductive shutdown voltage to 2L+ (-47 V).
Controlling a digital input.
Load resistance range:
Lower limit: 12 Ω.
Upper limit: 4 kΩ.
Output voltage for signal "1", min: 2L+ (-0,8 V).
Output current:
For signal "1" rated value: 2 A.
For signal "0" residual current, max: 0.5 Ma.
Cable length:
Shielded, max: 30 m.
Unshielded, max: 30 m.
Isolation tested with 707 V DC (type test).
Width: 45 mm.
Height: 130 mm.
Depth: 35 mm; without terminal module.
