SIMATIC ET 200pro 8DQ 24 V DC/0.5 A
SKU: 6ES7142-4BF00-0AA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC DP: Electronic modules for ET 200 PRO 8 DO 24 V DC, 0.5 A.
Diagnostic module for bus and connection modules (IO 6ES7194-4.00-0AA0, order separately) included.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Supply voltage for load voltage 2L+:
Rated value (DC): 24 V.
Short-circuit protection: per channel, electronic.
Reverse polarity protection: against destruction; load increasing.
Input current:
From load voltage 2L+ (without load), max: 30 mA.
From backplane bus 3.3 V DC, max: 30 mA.
Typical power loss: 2 W.
Digital outputs:
Number of digital outputs: 8.
Short-circuit protection.
Response threshold: 0.7 A.
Limitation of inductive shutdown voltage to 2L+ (-47 V).
Controlling a digital input: Isolation between 1L+ and 2L+ is no longer provided, as 1M and 2M are jumped.
Load resistance range:
Lower limit: 48 Ω.
Upper limit: 4 kΩ.
Output voltage for signal "1", min: 2L+ (-0,8 V).
Output current:
For signal "1" rated value: 0.5 A.
For signal "0" residual current, max: 0.5 Ma.
Cable length:
Shielded, max: 30 m.
Unshielded, max: 30 m.
Isolation tested with 707 V DC (type test).
Width: 45 mm.
Height: 130 mm.
Depth: 35 mm.
