SIMATIC ET 200pro 4AI RTD HF
SKU: 6ES7144-4JF00-0AB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC DP, Electronic modules for ET 200 PRO 4 AI RTD High Feature, Pt100; PT200; PT500; Pt1000; NI100; NI200; NI500; NI1000; Channel diagnostics, including bus and connection modules. Order IO 6ES7194-4.00-0AA0 individually.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Supply voltage:
Rated value (DC): 24 V.
Reverse polarity protection: against destruction.
Input current:
From supply voltage 1L+, max: 27 mA; Typical.
From backplane bus 3.3 V DC, max: 10 mA; Typical.
Typical power loss: 0.7 W.
Analog inputs:
Number of analog inputs: 4.
Constant measurement current for resistance-type transmitter: 1.25 mA; 1.25 / 0.5 mA depending on measuring range.
Cycle time (all channels) max: 83 MS; 83 MS at 50 Hz; 69 MS at 60 Hz.
Technical unit for temperature measurement adjustable: Degrees Celsius/degrees Fahrenheit.
Input ranges (rated values), resistance thermometer:
Ni 100: 10 000 kΩ.
Ni 1000: 10 000 kΩ.
Ni 120: 10 000 kΩ.
Ni 200: 10 000 kΩ.
Ni 500: 10 000 kΩ.
Pt 100: 10 000 kΩ.
Pt 1000: 10 000 kΩ.
Pt 200: 10 000 kΩ.
Pt 500: 10 000 kΩ.
Input ranges (rated values), resistors:
0 to 150 ohms: 10 000 kΩ.
0 to 300 ohms: 10 000 kΩ.
0 to 600 ohms: 10 000 kΩ.
0 to 3000 ohms: 10 000 kΩ.
PTC: 10 000 kΩ.
Shielded maximum cable length: 30 m.
Isolation tested with 707 V DC (type test).
Width: 45 mm.
Height: 130 mm.
Depth: 35 mm.
