SIMATIC ET 200pro 4AI TC HF
SKU: 6ES7144-4PF00-0AB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC DP, Electronics module for ET200 PRO, 4 AI TC High Feature, TC type B, E, J, K, L, N, R, S, T, Voltage +/-80 mV, Channel diagnostics, included bus module, Connection module IO 6ES7194-4.00-0AA0, order separately.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Supply voltage:
Rated value (DC): 24 V.
Reverse polarity protection: against destruction.
Input current:
From supply voltage 1L+, max: 34 mA; Typical.
From backplane bus 3.3 V DC, max: 20 mA; Typical.
Typical power loss: 0.7 W.
Analog inputs:
Number of analog inputs: 4.
Permissible input voltage for voltage input (destruction limit), max: 20 V.
Cycle time (all channels) max: Number of active channels per module x basic conversion time.
Technical unit for temperature measurement adjustable: °C/°F/K.
Input ranges (rated values), voltages:
-80 mV to +80 Mv: 10 MΩ.
Input ranges (rated values), thermocouples:
Type B: 10 MΩ.
Type E: 10 MΩ.
Type J: 10 MΩ.
Type K: 10 MΩ.
Type L: 10 MΩ.
Type N: 10 MΩ.
Type R: 10 MΩ.
Type S: 10 MΩ.
Type T: 10 MΩ.
Shielded maximum cable length: 30 m.
Isolation tested with 707 V DC (type test).
Width: 45 mm.
Height: 130 mm.
Depth: 35 mm.
