SIMATIC ET 200pro 4AQ U HF
SKU: 6ES7145-4FF00-0AB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC DP, Electronic modules for ET 200 PRO 4 AO U High Feature, +-10 V; 0...10V; 1...5V, Channel Diagnostics; includes bus module, Connection module IO 6ES7194-4.00-0AA0 (order separately).
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Supply voltage:
Rated value (DC): 24 V.
Reverse polarity protection: against destruction.
Input current:
From supply voltage 1L+, max: 65 Ma.
From backplane bus 3.3 V DC, max: 10 mA.
Actuator supply:
Number of outputs: 4.
Short-circuit protection: per module.
Output current, up to 55 °C, max: 1 A.
Typical power loss: 1.7 W.
Analog outputs:
Number of analog outputs: 4.
Voltage output, short-circuit protection: per channel, electronic to chassis.
Voltage output, short-circuit current, max: 50 mA.
Cycle time (all channels) max: 3 MS.
Output ranges, voltage:
0 to 10 V.
1 V to 5 V.
-10 V to +10 V.
Shielded maximum cable length: 30 m.
Isolation tested with 707 V DC (type test).
Width: 45 mm.
Height: 130 mm.
Depth: 35 mm.
