SIMATIC ET 200pro 4AQ I HF
SKU: 6ES7145-4GF00-0AB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC DP, Electronic modules for ET 200 PRO 4 AO I High Feature, +-20 mA; 0...20 mA; 4-20 mA; Channel diagnostics; includes bus module and connection module IO 6ES7194-4.00-0AA0 (order separately).
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Supply voltage:
Rated value (DC): 24 V.
Reverse polarity protection: against destruction.
Input current:
From supply voltage 1L+, max: 110 mA.
From backplane bus 3.3 V DC, max: 10 mA.
Actuator supply:
Number of outputs: 4.
Short-circuit protection: per module.
Output current, up to 55 °C, max: 1 A.
Typical power loss: 2.3 W.
Analog outputs:
Number of analog outputs: 4.
Voltage output, short-circuit protection: Yes; per module, electronic to frame.
Current output, no-load voltage, max: 16 V.
Cycle time (all channels) max: 3 MS.
Output ranges, current:
0 to 20 mA.
-20 mA to +20 mA.
4 mA to 20 mA.
Shielded maximum cable length: 30 m.
Isolation tested with 707 V DC (type test).
Width: 45 mm.
Height: 130 mm.
Depth: 35 mm.
