SIMATIC ET 200pro 4/8F-DI/4F-DQ 24 V DC/2 A PROFIsafe
SKU: 6ES7148-4FC00-0AB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC ET200 PRO and DP Electronic module 4/8 F-DI/4 F-DO 24 V DC/2A PROFI that is fail-safe, up to Category 4 (EN 954-01)/SIL3 (IEC61508)/PLE (ISO13849), with an overall width of 90 mm.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Supply voltage, Rated value (DC): 24 V.
Input current:
From supply voltage 1L+, max: 100 mA; Typical.
from load voltage 2L+ (without load), max: 50 mA; Typical.
From backplane bus 3.3 V DC, max: 20 mA.
Typical power loss: 5.8 W.
Digital inputs, Number of digital inputs: 8.
Input current for signal "1": 3.7 mA.
Digital outputs:
Number of digital outputs: 4.
Short-circuit protection.
Controlling a digital input: digital output, according to IEC 61131-2, type 2.
Output current for signal "1" rated value: 2 A.
Width: 90 mm.
Height: 130 mm.
Depth: 65 mm.
