SIMATIC S7-1200, Digital output SB 1222, 4 DQ, 5V DC 200kHz
SKU: 6ES7222-1AD30-0XB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
This signal board adds 4 solid-state digital outputs to S7-1200 CPUs, optimized for fast switching at up to 200 kHz.
It’s ideal for driving TTL-level devices, pulse outputs, or interfacing with high-speed digital actuators.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Electrical Characteristics:
Rated Output Voltage: 5 V DC.
Output Type: MOSFET, solid-state (sinking/sourcing).
Switching Capacity:
Max 0.1 A per channel (resistive load).
Output Voltage Levels:
Signal “0”: Max 0.2 V.
Signal “1”: Min L+ – 0.7 V, Max 6 V.
Output Current:
Rated: 0.1 A.
Max permissible: 0.1 A.
Short-Circuit Protection: Not available.
Power Loss: 0.5 W.
Backplane Bus Current: 35 mA.
Digital Outputs:
Channels: 4.
Group Configuration: Single group of 4.
Max Frequency: 200 kHz.
Cable Length:
Shielded: 50 m.
Mechanical & Environmental:
Dimensions (W x H x D): 38 × 62 × 21 mm.
Mounting: Direct CPU attachment.
Protection Rating: IP20.
Operating Temp: –20 to +60 °C.
Storage Temp: –40 to +70 °C.
Humidity: Up to 95% (non-condensing).
Weight: ~35 g.
Compliance & Approvals:
CE, UL, CSA, FM, RCM, KC.
Marine: DNV, LRS, BV, RMRS, CCS.
EMC & RoHS Compliant.
Environmental Confirmations: China RoHS, UKCA, IECEx, ATEX.
