Siemens S7-1200 Signal boards - digital DQ 4x24 V DC 0.1 A 200 kHz
SKU: 6ES7222-1BD30-0XB0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
This signal board provides 4 solid-state digital outputs with fast switching capability up to 200 kHz, ideal for controlling actuators, relays, or pulse-driven devices in industrial automation environments.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Electrical Characteristics:
Rated Output Voltage: 24 V DC.
Output Type: MOSFET, solid-state (sinking/sourcing).
Switching Capacity:
Max 0.1 A per channel (resistive load).
Load Resistance:
Upper limit: 11 Ω.
Output Voltage Levels:
Signal “0”: Max 1 V (with 10 kΩ load).
Signal “1”: Min L+ – 1.5 V.
Output Current:
Rated: 0.1 A.
Max permissible: 0.1 A.
Short-Circuit Protection: Not available.
Power Loss: 0.5 W.
Backplane Bus Current: 35 mA.
Digital Outputs:
Channels: 4.
Group Configuration: Single group of 4.
Max Frequency: 200 kHz.
Cable Length:
Shielded: 50 m.
Mechanical & Environmental:
Dimensions (W x H x D): 38 × 62 × 21 mm.
Mounting: Direct CPU attachment.
Protection Rating: IP20.
Operating Temp: –20 to +60 °C.
Storage Temp: –40 to +70 °C.
Humidity: Up to 95% (non-condensing).
Weight: ~35 g.
Compliance & Approvals:
CE, UL, CSA, FM, RCM, KC.
Marine: DNV, LRS, BV, RMRS, CCS, ABS, RINA, NK.
Hazardous Location: ATEX, IECEx, CCC-Ex.
Environmental Product Declaration (EPD).
