SIMATIC S7-1500 Slot cover with active backplane PU 5
SKU: 6ES7590-0CA00-0AA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC S7-1500 / ET 200MP; slot cover for the S7-1500's active backplane bus that protects against ESD and can be mechanically attached to the mounting rail.
empty slots must have a slot cover!
Five units per packing unit.
General information:
Product type designation: Slot cover.
Degree and class of protection:
IP degree of protection: IP20
Buy currently uses Select Automation shop pricing and checkout.
Ambient conditions:
Ambient temperature during operation:
min.: -30 °C.
max.: 60 °C.
horizontal installation, min.: -30 °C.
horizontal installation, max.: 60 °C.
vertical installation, min.: -30 °C.
vertical installation, max.: 40 °C.
Ambient temperature during storage/transportation:
min.: -40 °C.
max.: 70 °C.
Air pressure acc. to IEC 60068-2-13:
Operation, min.: 795 hPa.
Operation, max.: 1 040 hPa.
Storage/transport, min.: 660 hPa.
Storage/transport, max.: 1 140 hPa.
Altitude during operation relating to sea level:
Installation altitude above sea level, max.: 5 000 m.
Relative humidity:
Operation at 25 ℃ without condensation, max.: 95 %.
Dimensions:
Width: 25 mm.
Height: 150 mm.
Depth: 32 mm.
