SIMATIC S7-1500 CPU 1508S F V21.9
SKU: 6ES7672-8FC01-0YA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
SIMATIC S7-1500 Failsafe, Software Controller CPU 1508S F Single License for one installation, R-SW, SW, and documentation on DVD, license key on USB flash drive, R-SW Class A, 6 languages (de, en, it, fr, es, zh).
Executable in Windows 7/10 reference HW: IPC627D, IPC827D, IPC677D, IPC4x7E, IPC6x7E, and IPC8x7E.
Phasing out date: 01/01/25.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Software version: V21.9.
SIMATIC memory card required: Use of the PC mass storage.
Integrated work memory:
12.5 Mbyte (for program).
100 Mbyte (for data).
50 Mbyte (for CPU function library of CPU Runtime).
Integrated load memory: 1 024 Mbyte (on PC mass storage).
Backup:
UPS: all memory areas declared retentive.
Non-volatile memory: Depending on PC hardware.
Interfaces:
Number of interfaces: 3.
PROFINET interfaces: 2.
PROFIBUS interfaces: 1.
Interface type: CP 1625.
Number of connections: 192.
Interface type: Onboard PROFINET / IE interface X2 of the SIMATIC IPC, Intel Springville i210T.
Number of connections: 192.
Interface type: PROFIBUS with CP 5622, CP 5622 onboard.
Number of connections: 44.
Interface type: PROFIBUS with CP 5623.
Number of connections: 44.
Open Development interfaces: Size of ODK SO file, max.: 9.8 Mbyte.
