SIEMENS SIMATIC S7-300 Loadable drivers for CP 341, Modbus master (RTU format),
SKU: 6ES7870-1AA01-0YA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
MODBUS Master V3 with SIMATIC S7.
1 license for one installation of R-SW, SW, and DOCU on CD, HW dongle, Class A, three languages (de, de, fr, en fr), executable in STEP 7 V4.02 or above, reference hardware: CP 341 and CP 441-2.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Standards, approvals, certificates: developed in accordance with IEC 61131.
Operating systems: Windows XP, Windows 7.
Software class: A.
Target system: SIMATIC CP 341/CP 441-2.
Authorization/licenses: Single license (EL).
Adjustable parameters:
Response monitoring time: 100 MS to 25.5 s in 100-ms grid.
Factor for the character delay time: 1 or 10.
Modem operation (ignore filler characters): with/without.
RS 485 operation for 2-wire connection: with/without.
Pre-assignment of receive circuit on application of the X.27 interface module.
Communication data:
CRC polynomial: X16 + x15 + x2 + 1.
Receive mailbox: Specified on BRCV.
Modbus protocol: with RTU format.
Implemented function codes: 01, 02, 03, 04, 05, 06, 07, 08, 11, 12, 15, 16.
Broadcast Message: possible.
Transmission rate: 300 bit/s to 76 800 bit/s; (TTY to 19 200 bit/s).
Character delay time: 3.5 characters or multiples.
