SIEMENS SIMATIC S7-300 SIMATIC Micro Memory Card 64 KB
SKU: 6ES7953-8LF31-0AA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
This MMC is a 64 KB Flash-EPROM memory module for SIMATIC S7-300, C7, and ET 200 systems.
It is critical for CPU functioning, program storage, and data preservation, particularly in vintage or compact automation systems.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Memory Characteristics:
Type: Flash-EPROM.
Capacity: 64 KB.
Write/Delete Cycles: ≥ 100,000.
Data Retention: ≥ 10 years (after final programming).
Physical Dimensions:
Width: 24 mm.
Height: 32 mm.
Depth: 1.4 mm.
Weight: ~2 g.
Compliance & Approvals:
CE, UKCA, UL, RCM.
Classified under eClass (27-24-22-12) and ETIM (EC000192) standards.
UNSPSC: 43201402.
Application Notes:
Compatible with S7-300 CPUs like 317-2 PN/DP and 319-3 PN/DP.
Required for CPU boot and program execution.
Ideal for compact programs, parameter sets, or legacy system backups.
Not suitable for high-volume logging or large-scale data buffering.
