SIMATIC DP, Connection plug for PROFIBUS up to 12 Mbit/s
SKU: 6ES7972-0BA61-0XA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
PROFIBUS bus connector, RS 485, Fast Connect, no programming port.
SIMATIC DP, PROFIBUS connection plug up to 12 Mbit/s with 35-degree cable outlet.
Capable of connecting PROFIBUS stations to the PROFIBUS bus wire.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Transfer rate / with PROFIBUS DP: 9.6 kbit/s - 12 Mbit/s.
Number of electrical connections:
For PROFIBUS cables: 2 connections.
For network components or terminal equipment: 1 connection.
Type of electrical connection:
For PROFIBUS cables: Integrated insulation displacement terminals for 2-core PB FC installation cables.
For network components or terminal equipment: 9-pin sub-D connector.
Design of terminating resistor: Resistor combination integrated and connectable via slide switch.
Material / of the enclosure: plastic.
Locking mechanism design: Screwed joint.
Type of cable outlet: 35-degree cable outlet.
Width: 15.8 mm.
Height: 54 mm.
Depth: 39.5 mm.
Ambient temperature:
During operation: -25 ... +60 °C.
During storage: -40 ... +70 °C.
During transport: -40 ... +70 °C.
Protection class IP: IP20.
