SIMATIC ECC CHAdeMO conductive charging of electric vehicles
SKU: 6FE1263-8FB10-0AA0
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
According to the CHAdeMO 1.x-2.0 specification, SIMATIC ECC CHAdeMO allows for function block single licensing and e-vehicle connection.
In conjunction with SIMATIC PN/CA 6BK1620-0AA00-0AA0 and ET 200SP CM CAN 6ES7137-6EA00-0BA0.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Engineering with:
STEP 7 TIA Portal configurable/integrated from version: STEP 7 V15.1 or higher.
Runtime software:
Target system: S7-1200, S7-1500.
Local data requirements: 227 Kbyte.
FB length in RAM, max: 1 099 Kbyte.
Multi-instance capable.
Programming language: STL, SCL.
Languages:
German.
English.
