RS 485 bus terminal for PROFIBUS Transfer rate: 9.6 kbps to 1500 kbps
SKU: 6GK1500-0AB00
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
Product Type Designation Bus terminal RS 485 (3m).
PROFIBUS transfer rate: 9.6 Kbit/s to 1500 Kbit/s via bus terminal RS 485 with a 3.0 m plug-in connection.
Transfer rate:
Transfer rate:
With PROFIBUS: 9.6 kbit/s ... 1.5 Mbit/s.
Buy currently uses Select Automation shop pricing and checkout.
Interfaces:
Number of electrical connections:
For PROFIBUS cables: 2.
Type of electrical connection:
For PROFIBUS cables: Screw terminals.
Mechanical data:
Material / of the enclosure: plastic.
Design, dimensions and weights:
Width: 50 mm.
Height: 138 mm.
Depth: 53 mm.
Net weight: 411 g.
Fastening method:
35 mm top hat DIN rail mounting: Yes.
Product features, product functions, product components / general:
Product feature:
Silicon-free: Yes.
Standards, specifications, approvals:
Reference code:
According to IEC 81346-2:2019: KFA.
