XF202-2P IRT managed IE IRT switch, 2x 10/100 Mbit/s RJ45 ports, 2x 100 Mbit/...
SKU: 6GK5202-2BH00-2BD2
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The XF202-2P IRT-controlled IE IRT switch has two 10/100 Mbit/s RJ45 ports and two 100 Mbit/s POF SC RJ connections.
Bus adapter constructed, error signalling contact with set pushbutton, redundant power supply, PROFINET IO device, network management.
Redundancy Manager is built-in, with an electronic handbook on CD-ROM and C-PLUG support as an option.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Transfer rate: 10 Mbit/s, 100 Mbit/s.
Number of electrical connections for network components or terminal equipment: 2.
Number of 100 Mbit/s SC-RJ-ports / for POF FOC / with push pull connection system: 2.
Number of electrical connections:
For signalling contact: 1.
For power supply: 1.
Type of electrical connection:
For signalling contact: 2-pole terminal block.
For power supply: 2-pole terminal block.
Design of the removable storage: C-PLUG.
Operating voltage / of the signalling contacts at DC / rated value: 24 V.
Operational current / of the signalling contacts at DC / maximum: 0.1 A.
Ambient temperature:
During operation: 0 ... 50 °C.
During storage: -40 ... +70 °C.
During transport: -40 ... +70 °C.
Relative humidity at 25 °C / without condensation / during operation / maximum: 95 %.
Protection class IP: IP20.
Design: compact.
Width: 100 mm.
Height: 117 mm.
Depth: 74 mm.
Fastening method: 35 mm top hat DIN rail mounting.
